Twidec/MV100-B10 Digital Display PID Temperature Controllers Thermostat Regulator AC 85V - 265V MY-104+ K Sensor Thermocouple + Heat Sink and Solid State Relay SSR 40 DA
Share Tweet
*Price and Stocks may change without prior notice
*Packaging of actual item may differ from photo shown
- Electrical items MAY be 110 volts.
- 7 Day Return Policy
- All products are genuine and original
- Cash On Delivery/Cash Upon Pickup Available
Twidec/MV100-B10 Digital Display PID Temperature Features
-
Product name: Temperature Controller MY-104 MV100-B10 ;Product name: solid state module relay SSR-40DA, 3-32VDC/24-380VAC; Product name: K-Type Thermocouple Sensor Dia: 6mm ,Cable Length: 2m(6.6ft).
-
Special note: After the temperature controller is turned on, the default is degree Fahrenheit；Digital Display PID : Support reading with Centigrade or Fahrenheit unit （factory default to Fahrenheit unit）; be able to display measured and Controller temperature ；Display Character: PV: 4 digital 9.9mm height Red LED Letters；SV: 4 digital 8mm height Green LED Letters；
-
Controller Front Panel Dimension: DIN 48mm(W)X48mm(L) ; Mounting hole size: DIN 45mm(W)X45mm(L) ；Total size ：DIN 48mm(W)X48mm(L)X74mm(H);
-
Power Supply Voltage: AC 85-265V 50/60Hz ；Input: K factory default to K type ; Output: Solid state relay SSR ; Alarm mode: factory default to 1 way High deviation alarm（can choose）;
-
Pacakge: 1x MV100 Controller ; 1 x 40A SSR ; 1 x K sensor ; 1x White Heat Sink ;1x English manual
About Twidec/MV100-B10 Digital Display PID Temperature
Temperature Controller Specification Front Panel Dimension: 51mm X 51mm/2"X2"(W*L) Hole Size：48mm X 48mm/1.9"x1.9"(W*L) Power Supply Voltage: 85-265VAC 50/60Hz Life expectancy of Relay: Mechanical≥10,000,000 operations Electrical≥10,000,000 operations Weight: Approx. 110g K-Type Thermocouple Temperature Sensor Specification Measuring Range: 0~600°F Probe Length: 6mmx20mm/0.23“x0.79“（D * L） Terminal: 2 Insulated forks; Thread:2 Meters Internal Insulation: Fibreglass; External Shielding: Metal Shield;Thread ： 1/4" SSR Single solid state relay Specifications Current : 40A Frequency : 50/60Hz output Voltage : 24-480vac Control Voltage : 3-32vdc The Total Includes 1Pcs x Twidec Temperature Controller 1Pcs x SSR-40DA 1Pcs x White Heat Sink 1Pcs x K Thermocouple 1Pcs xProduct Manual
